- The Cub Cadet XT1 ST54 FAB is powered by a 24 hp KOHLER 7000 Series twin cylinder engine.
- 54-inch fabricated, 11-gauge, triple-blade deck with AeroForce™ deck design that optimizes airflow and maximizes suction to reduce clumping during discharge and improves bagging performance while delivering the pristine Cub Cadet Signature Cut™.
- Optimized steering system for responsive handling gives a 16-inch turn radius a zero-turn feel.
- 3-year/no hour limit warranty (includes powertrain) and 5-year chassis and front axle unlimited hours/limited lifetime fabricated deck shell.
- Ideal for mowing up 2-4 acres of mostly flat terrain and a few obstacles.
You're shopping available inventory from
XT1 ST54 Features
Hydrostatic transmission for smooth clutchless operation with no shifting. Just push the pedal and go.
Ride with Comfort
Adjustable cut-and-sew high back seat with a 10° incline and slide slope provides elite comfort for an unrivaled mowing experience.
A Kohler 7000 Series twin-cylinder engine delivers high-performance power to tackle your yard.
AeroForce™ Cutting Deck
A heavy-duty fabricated AeroForce™ deck cutting system means fewer clumps, finer clippings and increased evenness.
Cast iron front pivot bar provides added durability and rugged performance.
Backed by a 3-year no hour limit warranty, 5-year frame warranty and lifetime limited fabricated deck shell warranty.
An experienced national dealer network delivers dedicated personal owner support, seven days a week.
Specs & Maintenance
- Engine Brand Kohler®
- Engine Model 7000 Series
- Engine Model Number KT735
- Engine Displacement 725cc
- Engine Output 24HP
- Starter Type Electric
- Fuel Tank Capacity 3.0 gal. US (11.36 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qt. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 12 amp regulated
- Fuel Gauge No
- Governor Mechanical
- Choke Choke-a-matic
- Air Filter Dual element
- Oil Filter Yes
- Fuel Delivery Carburetor
- Battery 230 CCA
- Battery Type AGM (Absorbent Glass Mat)
- Battery Voltage 12V
- Transmission Tuff Torq® K46
- Forward Speed 5.5 MPH / 8.6 km/h
- Reverse Speed 3 MPH / 4.8 km/h
- Rear Axle 3/4"
- Drive System Hydrostatic
- Transmission Control Foot Pedal
- Transmission Housing Aluminum
- Rear Differential Lock No
- Deck Cutting Width 54 in
- Deck Wash Yes
- Deck Material 11-gauge steel
- Deck Engagement (PTO) Electric
- Deck Construction Fabricated
- Blade(s) Three
- Deck Lift Manual
- Cutting Height Range 1" - 4"
- Anti-Scalping Four gauge wheels plus roller
- Deck Positions 12
- Warranty 3-year unlimited hours
- Frame Warranty 5-year unlimited hours
- Front Axle Warranty 5-year unlimited hours
- Deck Shell Warranty Lifetime limited
- Commercial Warranty No
- Frame Robotically welded
- Turning Radius 16"
- Bumper Steel tube
- Rear Tow Hitch Yes
- Corrosion Protection Yes
- Front Pivot Bar Cast iron
- Cruise Control Yes
- Brakes Disc
- Seat Type 15" high-back
- Armrests No
- Seat Adjustment Lever
- Floor Mats Rubber
- Bearing Type Poly Bushing
- Rear Tires 22"x 9.5"-12"
- Front Tires 16"x 6.5"-8"
- Tire Tread Turf Saver
- Mulch Kit Available Separately
- Headlight(s) Dual-LED
- Cup Holder Yes
- Operator Presence System Yes
- Model Number 13AQA2TMA10
- Series XT1® Enduro Series™
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
