XT2 LX42
Documents and Guides
- A strong 20 HP Kohler® engine delivers reliable power to tackle your yard
- 42-in. heavy-duty fabricated AeroForce™ deck cutting system delivers a best-in-class cut with fewer clumps, finer clippings and increased evenness
- Tuff Torq Hydrostatic transmission, no shifting, just push the pedal and go
You're shopping available inventory from

XT2 LX42 Features
Dealer Exclusive

Available exclusively at your Cub Cadet dealer.
Front-End Protection

A heavy duty bumper comes standard on all XT2 Enduro Series models.
AeroForce™ Cutting Deck

XT2 Enduro Series models are equipped with a fabricated AeroForce™ deck cutting system means fewer clumps, finer clippings and increased evenness.
Adjustable Cut-and-Sew Seat

A 15-inch seat with armrests and 10-degree incline and slide slope provides elite comfort for an unrivaled mowing experience.
Optimized Steering

Automotive-inspired handling with an optimized steering system delivers a one-touch, 16-inch turning radius.
Versatility

Year-round attachments maximize the versatility of your Cub Cadet Enduro Series tractor.
LED Headlights

LED headlights come standard on every Enduro Series model, allowing you to see clearer in low-visibility conditions.
Smoother Ride

Enhanced front wheel bearings for friction-free wheel rotation.
Tuff Torq™ Transmission

Hydrostatic transmissions from Tuff Torq™ feature a robust transaxle with a smooth response making it easy to operate at consistent speeds up to 5.5 MPH.
Strong Warranty

Backed by a 3-year no hour limit warranty, 5-year frame warranty and lifetime limited fabricated deck shell warranty.
Specs & Maintenance
Engine
- Engine Brand Kohler®
- Engine Model 7000 Series HD
- Engine Model Number KT715
- Engine Displacement 725cc
- Engine Output 20HP
- Starter Type Electric
- Fuel Tank Capacity 3.0 gal. US (11.36 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qts. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 12 amp regulated
- Fuel Gauge No
- Governor Mechanical
- Choke Choke-a-matic
- Air Filter Single element
- Oil Filter Yes
- Fuel Delivery Carburetor
Battery
- Battery 210 CCA
- Battery Type AGM (Absorbent Glass Mat)
- Battery Voltage 12V
Drive System
- Transmission Tuff Torq® K46
- Forward Speed 5.5 MPH / 8.6 km/h
- Reverse Speed 3 MPH / 4.8 km/h
- Rear Axle 1"
- Drive System Hydrostatic
- Transmission Control Foot Pedal
- Transmission Housing Cast aluminum
- Rear Differential Lock No
Cutting Deck
- Deck Cutting Width 42 in
- Deck Wash Yes
- Deck Material 11-gauge steel
- Deck Engagement (PTO) Manual
- Deck Construction Fabricated
- Blade(s) 2
- Deck Lift Manual
- Cutting Height Range 1" - 4"
- Anti-Scalping 2 gauge wheels
- Deck Positions 12
Warranty
- Warranty 3-year unlimited hours
- Frame Warranty 5-year limited
- Front Axle Warranty 5-year unlimited hours
- Deck Shell Warranty Lifetime limited
- Commercial Warranty No
Chassis
- Frame Robotically welded
- Turning Radius 16"
- Bumper Steel Tube
- Rear Tow Hitch Yes
- Corrosion Protection Yes
- Front Pivot Bar Cast iron
Controls
- Cruise Control Yes
- Brakes Disc
Comfort
- Seat Type 15" High-back
- Armrests Yes
- Seat Adjustment Lever
- Floor Mats Rubber
Wheels
- Bearing Type Ball Bearing
- Rear Tires 20" x 8" -8”
- Front Tires 15"x6"-6"
- Tire Tread Multi Trac
Additional Specifications
- Mulch Kit Available separately
- Headlight(s) Dual LED
- Cup Holder Yes
- Operator Presence System Yes
- Model Number 13APA1TEA10
Specifications
- Series XT2® Enduro Series™
Disclaimers
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
Model | Manual | Form Number | |
---|---|---|---|
13APA1TEA10 | MAN:OPER:DIG:TRILING:NX15 | ||
MAN:OPER:DIG:TRILING:NX15 | 769-25738B | Download | |
MAN:OPER:DIG:TRILING:NX15 | 769-25738C | Download | |
MAN:OPER:DIG:TRILING:NX15 | 769-25738D | Download | |
SHEET:SUP:BILING:EPA:EVP:20-21 | 769-25879 | Download | |
SHEET:SUP:BILING:EPA:EVP:21-22 | 769-26272 | Download | |
SHEET:SUP:BILING:EPA:EVP:22-23 | 769-26607 | Download | |
SHEET:SUPP:WARR/PARTS:CC NX15 | 769-23211C | Download | |
SHEET:SUPP:WARR/PARTS:CC NX15 | 769-26638 | Download | |
SHEET:SUPP:WARR/PARTS:CC NX15 | 769-26638A | Download |
