- The Cub Cadet XT1 LT42B is powered by a Briggs & Stratton Professional Series single cylinder 540cc engine
- 42-inch stamped, 13-gauge, twin-blade deck with 12 cutting positions.
- Equipped with an optimized steering system for responsive handling to give a 16-inch turn radius a zero-turn feel.
- 3-year/no hour limit warranty (includes powertrain) and 5-year chassis and front axle unlimited hours.
- Ideal for mowing up to 1.5 acres of mostly flat terrain and a few obstacles.
- Tuff Torq foot controlled hydrostatic transmission, no shifting - just push the pedal and go
You're shopping available inventory from
XT1 LT42B Features
Hydrostatic transmission helps provide smooth operation, no shifting, just push the pedal and go.
Ride with Comfort
Adjustable cut and sew high back 15-in. seat with a 10-degree incline and slide slope designed to provide comfort for an excellent mowing experience.
Heavy Duty Cutting Deck
A stamped deck built with strong materials and an exceptional belt design while delivering a premium cut.
Cast iron front pivot bar is built to provide strength and rugged performance.
Limited 3-year no hour limit warranty and 5-year frame limited warranty for peace of mind
Backed by expert service and knowledgeable support from the nationwide network of Cub Cadet® dealers.
Specs & Maintenance
- Engine Brand Briggs & Stratton®
- Engine Model Professional Series
- Engine Model Number 33S877-0038
- Engine Displacement 540cc
- Engine Output 19HP
- Starter Type Electric
- Fuel Tank Capacity 3.0 gal. US (11.36 L)
- Cylinders Single
- Engine Start Ignition Key
- Engine Oil Capacity 1.5 qt. US (1.42 L)
- Lubrication Fully pressurized
- Charging System 3 Amp Dual Circuit
- Fuel Gauge No
- Governor Mechanical
- Choke Choke-a-matic
- Air Filter Dual element
- Oil Filter Yes
- Fuel Delivery Carburetor
- Battery 230 CCA
- Battery Type AGM (Absorbent Glass Mat)
- Battery Voltage 12V
- Transmission Tuff Torq® TL-200
- Forward Speed 5.5 MPH / 8.6 km/h
- Reverse Speed 3 MPH / 4.8 km/h
- Rear Axle 3/4"
- Drive System Hydrostatic
- Transmission Control Foot Pedal
- Transmission Housing Aluminum
- Rear Differential Lock No
- Deck Cutting Width 42 in
- Deck Wash Yes
- Deck Material 13-gauge steel
- Deck Engagement (PTO) Manual
- Deck Construction Stamped
- Blade(s) Two
- Deck Lift Manual
- Cutting Height Range 1" - 4"
- Anti-Scalping Two gauge wheels
- Deck Positions 12
- Warranty 3-year unlimited hours
- Frame Warranty 5-year unlimited hours
- Front Axle Warranty 5-year unlimited hours
- Deck Shell Warranty 3-year unlimited hours
- Commercial Warranty No
- Frame Robotically welded
- Turning Radius 16"
- Bumper No
- Rear Tow Hitch Yes
- Corrosion Protection Yes
- Front Pivot Bar Cast iron
- Cruise Control Yes
- Brakes Disc
- Seat Type 15" high-back
- Armrests No
- Seat Adjustment Lever
- Floor Mats Rubber
- Bearing Type Poly Bushing
- Rear Tires 20"x 8"-8"
- Front Tires 15"x 6"-6"
- Tire Tread Turf Saver
- Mulch Kit Available Separately
- Headlight(s) Dual-LED
- Cup Holder Yes
- Operator Presence System Yes
- Model Number 13ALA9TSA10
- Series XT1® Enduro Series™
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
