PRO Z 960 S KW
Documents and Guides
- 35 HP Kawasaki FX1000v (999cc) engine and 16cc Parker HTG transmission
You're shopping available inventory from

PRO Z 960 S KW Features
Unmatched Hillside Confidence

Cub Cadet's exclusive zero-turn steering wheel control allows you to conquer slopes up to 20 degrees (32% grade).
Choose Your Comfort Level.

An air-ride seat allows riders to adjust seat firmness to their personal preference with elastic vibration control, isolation-dampening system, angle-back adjustment, adjustable padded armrests and adjustable lumbar support.
Less Maintenance, Less Downtime

Maintenance-free spindles and pullys deliver peak performance with limited downtime.
Decks Built to Last

Tackle the toughest conditions with a triple-7-gauge steel cutting deck: a 7-gauge deck shell with 7-gauge top and bottom reinforcements.
Nationwide Support

3-year, no-hour-limit commercial warranty and 5-year,1,750-hour limited deck warranty and a nationwide network of Cub Cadet dealers.
Control Your Own Way.

Whether you prefer our custom lap bar designs or our innovative steering options, the PRO Z lineup offers you great control to match your crew’s needs.
Specs & Maintenance
Engine
- Engine Brand Kawasaki®
- Engine Model FX Series
- Engine Model Number 1000V
- Engine Displacement 999cc
- Engine Output 35HP
- Fuel Tank Capacity Dual 7.45 gal. US (28.2 L)
- Cylinders Twin
- Engine Start Ignition Key
- Engine Oil Capacity 2.0 qt. US (1.89 L)
- Lubrication Fully pressurized
- Charging System 15 amp regulated
- Fuel Gauge Electronic
- Choke Separate Choke
- Air Filter High Density
- Oil Filter Yes
- Fuel Delivery Carburetor
Drive System
- Transmission Parker HTG 16cc pump / 310cc wheel motor
- Forward Speed 14 mph / 22.5 km/h
- Reverse Speed 6 mph / 9.5 km/h
Cutting Deck
- Deck Cutting Width 60 in
- Deck Material fabricated 7ga. (.187”) steel shell
- Deck Engagement (PTO) electronic fingertip engagement pto
- Deck Construction 7ga. top plate 7ga. bottom reinforcement ¼” rolled leading edge
- Spindle Construction 8" sealed cast aluminum housing (maintenance-free)
- Blade(s) 3 high-lift Marbain® blades / 18,500 fpm (approx.)
- Cutting Height Range 1” to 5” in 1/4” increments
- Anti-Scalping 2 front deck gauge wheels
- Deck Positions Foot pedal with spring assist 16 Positions
Chassis
- Frame Fully welded, full-length 3/8 x 5" laser cut steel / integrated tie-down slots
- Front Axle 2" x 3" solid axle tube with ISO dampening suspension
- ROPS 2" x 2" spring-latch tool-less foldable 3 position
- Bumper 5/16" Thick Steel rear engine guard/pre-drilled mounting points for attachments with integrated rear hitch
- Yokes 1/2" thick steel front yokes
Controls
- Cruise Control NA
- Brakes Hand-operated lever with integrated hydro pump release lever
- Steering Control High Performance Steering Wheel with electronic power steering & Foot-pedal Control
Comfort
- Seat Type Cushion with seat belt
- Armrests Padded arm rests
- Seat Suspension High-back Air-Ride suspension with EVC cushion, ISO mounted base (lateral suspension)
- Seat Adjustment Angle back adjust and lumbar support
Wheels
- Rear Tires 26"x12"-12"
- Front Tires 16"x6.5"-8"Kenda K505
- Tire Tread Turf Tread
Dimensions
- Dimensions L/W/H 88" L x 73" W x 48" H
- Weight (approx.) 1580 lbs.
Additional Specifications
- Hour Meter Crew Boss
- Discharge Chute High-density, impact-resistant rubber
- Cup Holder Intergrated into Side Pod
- Model Number 53TIHMUV050
Warranty
- Warranty 3 year / no hour limit commercial warranty and 5 year / 1,750 hour limited deck construction warranty
- Deck Shell Warranty 5 year / 1,750 hour limited deck construction warranty
- Commercial Warranty 3 year / no hour limit commercial warranty
Disclaimers
- Specifications Specifications subject to change without notice and without incurring obligation. Products depicted on website and other advertisements are for demonstration purposes only. Actual products offered for sale may vary in design, required attachments, safety features and non-functional appearance from. See other general disclaimers at the bottom of our website.
Model | Manual | Form Number | |
---|---|---|---|
53TIHMUV050 | MANL:OPER:ENGL:PRO Z XXXS | ||
MANL:OPER:ENGL:PRO Z XXXS | 769-26331A | Download | |
MANL:OPER:ENGL:PRO Z XXXS | 769-26803 | Download | |
MANL:OPER:ENGL:PRO Z XXXS (18) | 769-12364 | Download | |
MANL:OPER:ENGL:PRO Z XXXS (18) | 769-12364A | Download | |
MANL:OPER:ENGL:PRO Z XXXS (19) | 769-17795 | Download | |
MANL:OPER:ENGL:PRO Z XXXS (19) | 769-17795A | Download | |
MANL:OPER:ENGL:PRO Z XXXS (19) | 769-17795B | Download | |
MANL:OPER:ENGL:PRO Z XXXS (19) | 769-17795C | Download | |
MANL:OPER:ENGL:PRO Z XXXS (19) | 769-17795D | Download | |
MANL:OPER:ENGL:PRO Z XXXS (19) | 769-17795E | Download | |
MANL:OPER:ENGL:PRO Z XXXS (19) | 769-17795F | Download | |
MANL:OPER:ENGL:PRO Z XXXS (19) | 769-26331 | Download | |
MANL:OPER:FRENCH:PRO Z XXXS (19) | 769-17795_FR | Download | |
SHEET:SUP:BILING:EPA:EVP:06301 | 769-15171 | Download | |
SHEET:SUP:BILING:EPA:EVP:18-19 | 769-17171 | Download | |
SHEET:SUP:BILING:EPA:EVP:18-19 | 769-23590 | Download | |
SHEET:SUP:BILING:EPA:EVP:20-21 | 769-25879 | Download | |
SHEET:SUP:BILING:EPA:EVP:21-22 | 769-26272 | Download | |
SHEET:SUP:BILING:EPA:EVP:22-23 | 769-26607 | Download | |
SHEET:SUP:Warranty_Addendum_In | 769-26830 | Download |
